Catálogo Relmotor
Código A3156
ALTERNADOR · AS PARTS
AS PARTS
Repuesto de nuestra línea de importación directa, disponible para consulta comercial y despacho nacional.
Consultar disponibilidad
Los precios y las referencias cruzadas están disponibles para clientes con cuenta.
Ficha técnica
| Código | A3156 |
|---|---|
| Marca | AS PARTS |
| Unidad de venta | UN |
Alternadores
| Tensión [ V ] | 12 |
|---|---|
| Intensidad [ A ] | 120 |
| Tamaño A [ mm ] | 34.00 |
| Tamaño C [ mm ] | 56.00 |
| G [ qty. ] | 7 |
| O.D.1 [ mm ] | 56.00 |
| Polea | AFP |
| D.1 [ mm ] | 9.00 |
| D.2 [ mm ] | 8.50 |
| D.3 [ mm ] | 8.50 |
| D.4 [ mm ] | 8.50 |
| E.1 [ mm ] | 70.00 |
| E.2 [ mm ] | 70.00 |
| L.1 [ mm ] | 192.00 |
| Conector | PL_2303 |
| COM ID | 56 |
Medidas y denominaciones según AS-PL (cuenta cliente). Las letras corresponden al plano acotado que aparece entre las fotografías.
Compatibilidad
29 vehículos
Aplicaciones
MERCEDES-BENZ
- C-CLASS (W203) C 180 Kompressor (203.046) M271.946 2002–2007
- C-CLASS (W203) C 200 CGI Kompressor (203.043) M271.942 2003–2007
- C-CLASS (W203) C 200 Kompressor (203.042) M271.940 2002–2007
- C-CLASS (W203) C 230 Kompressor (203.040) M271.948 2004–2007
- C-CLASS Coupe (CL203) C 160 Kompressor (203.730) M271.921 2002–2008
- C-CLASS Coupe (CL203) C 180 Kompressor (203.746) M271.946 2002–2008
- C-CLASS Coupe (CL203) C 200 CGI Kompressor (203.743) M271.942 2003–2008
- C-CLASS Coupe (CL203) C 200 Kompressor (203.742) M271.940 2002–2008
- C-CLASS Coupe (CL203) C 220 M271.940 2002–2008
- C-CLASS Coupe (CL203) C 230 Kompressor (203.740) M271.948 2002–2008
- C-CLASS T-Model (S203) C 180 Kompressor (203.246) M271.946 2002–2007
- C-CLASS T-Model (S203) C 200 CGI Kompressor (203.243) M271.942 2003–2007
- C-CLASS T-Model (S203) C 200 Kompressor (203.242) M271.940 2002–2007
- C-CLASS T-Model (S203) C 230 Kompressor (203.240) M271.948 2004–2007
- CLC-CLASS (CL203) CLC 180 Kompressor (203.746) M271.946 2008–2011
- CLC-CLASS (CL203) CLC 200 Kompressor (203.741) M271.957 2008–2011
- CLK (C209) CLK 200 CGI (209.343) M271.942 2003–2009
- CLK (C209) CLK 200 Kompressor (209.341) M271.955 2006–2009
- CLK (C209) CLK 200 Kompressor (209.342) M271.940 2002–2009
- CLK Convertible (A209) CLK 200 CGI (209.343) M271.942 2003–2010
- CLK Convertible (A209) CLK 200 Kompressor (209.441) M271.955 2006–2010
- CLK Convertible (A209) CLK 200 Kompressor (209.442) M271.940 2003–2010
- E-CLASS (W211) E 200 Kompressor (211.041) M271.956 2006–2008
- E-CLASS (W211) E 200 Kompressor (211.042) M271.941 2002–2008
- E-CLASS (W211) E 200 NGT (211.042) M271.941 2004–2008
- E-CLASS T-Model (S211) E 200 Kompressor (211.241) M271.956 2006–2009
- E-CLASS T-Model (S211) E 200 T Kompressor (211.242) M271.941 2003–2009
- SLK (R171) 200 Kompressor (171.442) M271.944 2004–2011
- SLK (R171) 200 Kompressor (171.445) M271.954 2008–2011
